Premium Vibration Transmitter

(No reviews yet) Write a Review

Log in for pricing

SKU:
425.51-VR25-3
Weight:
70.00 Grams
Shipping:
Calculated at Checkout

Expected release date is December 2019

Premium Vibration Transmitter

Log in for pricing

Premium Vibration Transmitter

Log in for pricing

  • Premium  velocity (3 Hz-1000 Hz) / acceleration (3 Hz - 10 000 Hz) vibration transmitter (RMS or Peak).
  • No false trip thanks to improved MEMs design.
  • Suit machines with speed as low as  180 RPM.
  • Permanent monitoring of the overall vibration to DIN ISO 10816 (New ISO 20816)
  • Two-wire technology
  • Best reliability thanks to lifetime warranty Hermetic sealing (laser welded)
  • Optional temperature output
  • Optional Accelerarion raw output (for waveform analysis)
  • Large choice of connectors/cables for harsh industrial environment : M12 glass seal - Mil glass seal  - Overbraided Integral cable - Protection conduit.

Specifications
Measuring Range : see variants available.

Frequency Range velocity [Hz] :  3  ...  1000  (suit speed machine as low as 180 RPM)
Frequency Range acceleration [Hz] :  3  ...  10 000
Sensor Type : improved microelectromechanical system (MEMs)
Analog current output [mA] :  4    ...  20
Ambient temperature [°C] :  -55°C ...  120°C
Protection :  IP67; IP 68;  IP 69K
Material : AISI316L (DIN 1.4404)
Sealing : Hermetic laser welded >IP69K
Weight : 70 gr (2.5 Oz)
Size : Hex 22mm  Height 50mm

Typical applications
continuous trending of overall machine vibration in the rugged environments of industrial machinery monitoring. Direct connection to PLC with 4-20 mA card.

Features-by-features comparison versus competition :
-
> Check cross reference TAB

Sensor Strengths :
Model 425.51-VR25-3 (25 mm/s RMS with M12 connector) is kept on stock.

Model 425.51 offer distinctive configuration for specific market. For example, we can offer a 10mm/s RMS submersible sensor down to 150 metres with overbraided Polyurethane cable ......
Model 425.51 is available for OEM specific engraving.
Model 425.51-Y1 is available with exactly the same options along with additional full scale values and Atex zone 0 certification.

Datasheets    - English - PDF

Drawings        - English - PDF

Operating Manual - English - PDF
Operating Manual - Arabic - PDF
Operating Manual
 - French - PDF
Operating Manual - German - PDF


Legals:   Country of Origin : France      HS Code : 9031 80 80


204.01                                         -  Adhesive Pad
10.01-A01-E02-31-LL                  -  M12 cable assembly
191.01                                         -  Mounting Stud

Please read 425.01 FAQ tab ......
Please read 425.01 Cross Reference tab .....
